Wurth Elektronik 120μF 450V dc Aluminium Electrolytic Capacitor, Through Hole 22 (Dia.) x 46mm +105°C 22mm 10mm [861021483007]; 124-7493
0₫
Mã kho: 1247493
Liên hệ để có giá tốt (Vietnam: 0898.332.898, E-mail: SKF@nguyenxuong.com)
| THÔNG SỐ KỸ THUẬT | |
|---|---|
| Capacitance | 120 µF |
| Voltage | 450 V dc |
| Mounting Type | Through Hole |
| Technology | Electrolytic |
| Dimensions | 22 (Dia.) x 46mm |
| Depth | 46mm |
| Minimum Operating Temperature | -25°C |
| Diameter | 22mm |
| Maximum Operating Temperature | +105°C |
| Lead Pitch | 10mm |
| Lifetime | 2000h |
| Series | WCAP-AIG5 |
| Tolerance | ±20% |
| Leakage Current | 1080 μA |
| Polarised | Polar |
| Ripple Current | 820mA |
| Dissipation Factor | 0.2 |
