TDK-Lambda, DRL-60 DIN Rail Power Supply, 12V dc Output Voltage, 4A Output Current [DRL-60-12-1]; 137-0853
by TDK-Lambda
0₫
Mã kho: 1370853
Liên hệ để có giá tốt (Vietnam: 0898.332.898, E-mail: SKF@nguyenxuong.com)
| THÔNG SỐ KỸ THUẬT | |
|---|---|
| AC or DC Input Voltage | Ac |
| AC or DC Output Voltage | Dc |
| Input Voltage | 85 → 264V ac |
| Output Voltage | 12 V dc |
| Output Current | 0.166666666666667 |
| Power Rating | 60W |
| Number of Outputs | 1 |
| Electrical Phase | 1 |
| Type | Switch Mode |
| Height | 91mm |
| Width | 54mm |
| Load Regulation | 120mV |
| Standards Met | IEC 60068-2-27, IEC 60068-2-6, UL 1310, UL 508, UL 60950-1 |
| Depth | 55.6mm |
| Special Features | High In-Service Lifetime, Low No Load Consumption |
| Output Voltage Adjustment Range | 12 → 15V |
| Mounting Type | DIN Rail Mount |
| Minimum Temperature | -20°C |
| Ripple And Noise | 120mV |
| Series | DRL-60 |
| Maximum Temperature | +71°C |
