STMicroelectronics LDK320ADU120R, LDO Regulator, 200mA, 12 V, 0.5% 3+Tab-Pin, SOT-89 [LDK320ADU120R]; 175-1731
0₫
Mã kho: 1751731
Liên hệ để có giá tốt (Vietnam: 0898.332.898, E-mail: SKF@nguyenxuong.com)
| THÔNG SỐ KỸ THUẬT | |
|---|---|
| Output Voltage | 12 V |
| Dropout Voltage at Maximum Current | 350 mV @ 200 mA |
| Output Type | Fixed |
| Package Type | SOT-89 |
| Maximum Output Current | 200mA |
| Mounting Type | Surface Mount |
| Minimum Input Voltage | 2.5 V |
| Maximum Input Voltage | 18 V |
| Pin Count | 3+Tab |
| Number of Outputs | 1 |
| Polarity | Positive |
| Quiescent Current | 100µA |
| Accuracy | 0.005 |
| Minimum Operating Temperature | -40 °C |
| Maximum Operating Temperature | +125 °C |
| Enable | Yes |
| Dimensions | 4.6 x 2.6 x 1.6mm |
| Width | 2.6mm |
| Height | 1.6mm |
| Length | 4.6mm |
| Line Regulation | 0.05 %/V |
| Load Regulation | 0.003 %/mA |
