Panduit Copper Compression Butt Splice, Long Barrel, #14 -#10 AWG [SCL10-L]; PAO794

Name: Panduit Copper Compression Butt Splice, Long Barrel, #14 -#10 AWG [SCL10-L]; PAO794
Brand: Panduit
SKU: PAO794
Price: 125900.0 VND
Availability: InStock

by Panduit

125.900₫

(Giá chưa VAT).

Mã kho: PAO794

Mã nhà sản xuất: SCL10-L

Quy cách đóng gói: 1

Quantity

Liên hệ để có giá tốt (Vietnam: 0898.332.898, E-mail: SKF@nguyenxuong.com)

Wire Termination / Lugs Splices Split Bolts Accessories / Splices: Panduit SCL10-L

MÔ TẢ SẢN PHẨM

Copper Compression Butt Splice, Long Barrel, #14 -#10 AWG

_THÔNG SỐ KỸ THUẬT:

Product Type	Compression Connectors - Splices
Maximum Copper Conductor Size (AWG SOL)	#10
Maximum Copper Conductor Size (AWG STR)	#10
Minimum Copper Conductor Size (AWG SOL)	#14
Minimum Copper Conductor Size (AWG STR)	#14
Sub Brand	Pan-Lug
Copper Code Conductor Size (AWG)	#10
Barrel Type	Standard
Maximum Voltage (kV)	35
Base Material	Copper
Standards Met	UL Listed for Power and Grounding Applications in the U.S. and Canada; Meets UL467 Requirements for Grounding
Barrel Length (In.)	1.25
Barrel Length (mm)	31.75
Finish/Coating	Tin-Plated
Overall Length (In.)	1.25
Overall Length (mm)	31.75
Wire Strip Length (In.)	9/16
Wire Strip Length (mm)	14.3
UL Temperature Rating (°C)	90
UL Temperature Rating (°F)	194
CSA Temperature Rating (°C)	90
CSA Temperature Rating (°F)	194
