Red Button Tactile Switch, Single Pole Single Throw (SPST) 20 mA 3.85mm [EVQPF304R]; 756-1619
by Panasonic
0₫
Mã kho: 7561619
Liên hệ để có giá tốt (Vietnam: 0898.332.898, E-mail: SKF@nguyenxuong.com)
THÔNG SỐ KỸ THUẬT | |
---|---|
Contact Configuration | Single Pole Single Throw (SPST) |
Terminal Type | Through Hole |
Switch Operation | Momentary |
Actuator Length | 3.85mm |
Actuator Colour | Red |
Actuator Type | Push Plate |
Contact Current Rating | 20 mA |
Operating Force | 2.6 N |
Operating Temperature Range | -20 → +70°C |
Mechanical Life | 50000Cycles |
Minimum Operating Temperature | -20°C |
Maximum Operating Temperature | +70°C |
