Mean Well, DDR-30 DIN Rail Panel Mount Power Supply, 12V dc Output Voltage, 2.5A Output Current [DDR-30G-12]; 175-7778
by Mean Well
0₫
Mã kho: 1757778
Liên hệ để có giá tốt (Vietnam: 0898.332.898, E-mail: SKF@nguyenxuong.com)
| THÔNG SỐ KỸ THUẬT | |
|---|---|
| Input Voltage | 9 → 36V dc |
| Output Voltage | 12 V dc |
| Output Current | 2.5 A |
| Power Rating | 30W |
| Number of Outputs | 1 |
| Height | 90mm |
| Width | 35mm |
| Depth | 54.5mm |
| Minimum Temperature | -40°C |
| Mounting Type | DIN Rail Mount |
| Load Regulation | ±0.5% |
| Series | DDR-30 |
| Output Voltage Adjustment Range | 9 → 13.2V |
| Maximum Temperature | +85°C |
| MTBF | 483.3kh |
| Ripple And Noise | 75mV Pk-Pk |
