Littelfuse 0.75A Hold current, Radial Resettable Wire Ended Fuses, 240 V ac, 265 V ac [RF0627-000]; 174-0867
by Littelfuse
0₫
Mã kho: 1740867
Liên hệ để có giá tốt (Vietnam: 0898.332.898, E-mail: SKF@nguyenxuong.com)
THÔNG SỐ KỸ THUẬT | |
---|---|
Lead Orientation | Radial |
Trip Current | 1.5A |
Time to Trip | 18s |
Hold Current | 0.75 A |
Voltage Rating | 240 V ac, 265 V ac |
Maximum Current | 7.5 A |
Minimum Resistance | 0.31Ω |
Maximum Resistance | 830mΩ |
Power Dissipation | 2.6W |
Body Height | 23.4mm |
Body Length | 11.5mm |
Body Width | 4.8mm |
Wire Pitch | 6.1mm |
Wire Length | 5.1mm |
Maximum Operating Temperature | +85°C |
Minimum Operating Temperature | -40°C |
