IP56 Limit Switch Plunger, NO/NC, 250V [83732329]; 539-208
by Crouzet
0₫
Mã kho: 539208
Liên hệ để có giá tốt (Vietnam: 0898.332.898, E-mail: SKF@nguyenxuong.com)
| THÔNG SỐ KỸ THUẬT | |
|---|---|
| Actuator Type | Plunger |
| Pole and Throw Configuration | SP |
| Normal State Configuration | NO/NC |
| IP Rating | IP56 |
| Maximum Current | 0.208333333333333 |
| Maximum AC Voltage | 250V |
| Connection Type | Cable |
| Terminal Type | Wire Lead |
| Length | 49.5mm |
| Width | 49mm |
| Depth | 22mm |
| Minimum Operating Temperature | -5°C |
| Dimensions | 49.5 x 49 x 22 mm |
| Mechanical Life Minimum | 1000000 cycles |
| Maximum Operating Temperature | +70°C |
