Supercapacitor 2.5F 5.0V 140mohm 20uA [SCMS22C255PRBA0]; 186-2210
by AVX
0₫
Mã kho: 1862210
Liên hệ để có giá tốt (Vietnam: 0898.332.898, E-mail: SKF@nguyenxuong.com)
| THÔNG SỐ KỸ THUẬT | |
|---|---|
| Capacitance | 2.5 F |
| Voltage | 4.2 V dc, 5 V dc |
| Mounting Type | Through Hole |
| Minimum Operating Temperature | -40°C |
| Maximum Operating Temperature | +65 °C, +85 °C |
| Diameter | 10mm |
| Height | 22mm |
| Dimensions | 10 Dia. x 22mm |
| Lead Pitch | 15.5mm |
| Equivalent Series Resistance | 360mΩ |
| Series | SCM |
| Tolerance | 0/+100% |
| Capacitor Family | Supercapacitor |
| Polarised | Polar |
| Product Diameter | 10mm |
| Terminal Type | Radial |
| Tolerance Plus | 1 |
| Lead Diameter | 0.6mm |
