![Aim-TTi 59120-5640 1120942](http://nguyenxuong.com/cdn/shop/products/R1120942-01_444x272.jpg?v=1594386945)
Aim-TTi TGP3122 Pulse Generator 1 mHz → 25 MHz (Double Pulse), 1 mHz → 50 MHz (Pulse) [59120-5640]; 112-0942
by Aim-TTi
0₫
Mã kho: 1120942
Liên hệ để có giá tốt (Vietnam: 0898.332.898, E-mail: SKF@nguyenxuong.com)
THÔNG SỐ KỸ THUẬT | |
---|---|
Maximum Frequency | 25 (Double Pulse) MHz, 50 (Pulse) MHz |
Minimum Frequency | 1 mHz |
Maximum Pulse Width | 499.99999999 (Double Pulse) s, 999.99999999 (Pulse) s |
Modes | Burst, Double Pulse, Function/Arbitrary, Modulation, Noise, Pattern/PBRS, Pulse, Square, Sweep, Triggered |
Minimum Pulse Width | 10ns |
Maximum Pulse Delay | 999.99999996 (Double Pulse) s, 999.99999998 (Pulse) s |
Minimum Pulse Delay | 0ns |
Adjustable Output Amplitude | Yes |
Jitter | <30% |
Rise - Fall Time | 5 ns → 399.999999989 s (Double Pulse), 5 ns → 799.999999989 s (Pulse) |
Input Impedance | 10 kΩ |
Interface Type | GPIB, LAN, LXI, Remote, USB 2.0, USB Flash Drive |
Dimensions | 269 x 213.5 x 86.5 (Rack Mount) mm, 295 x 250 x 97 (Bench Top Mount) mm |
Weight | 3.2kg |
Minimum Operating Temperature | +5°C |
Length | 269 (Rack Mount) mm, 295 (Bench Top Mount) mm |
Maximum Operating Temperature | +40°C |
Model Number p | TGP3100 |
Width | 213.5 (Rack Mount) mm, 250 (Bench Top Mount) mm |
Height | 86.5 (Rack Mount) mm, 97 (Bench Top Mount) mm |
