STMicroelectronics, SMCJ18CA-TR [SMCJ18CA-TR]; 190-7560
0₫
Mã kho: 1907560
Liên hệ để có giá tốt (Vietnam: 0898.332.898, E-mail: SKF@nguyenxuong.com)
| THÔNG SỐ KỸ THUẬT | |
|---|---|
| Nominal Zener Voltage | 18V |
| Diode Configuration | Single |
| Number of Elements per Chip | 1 |
| Mounting Type | Surface Mount |
| Maximum Power Dissipation | 1.5 kW |
| Package Type | DO-214AB (SMC) |
| Zener Type | Bi-Directional |
| Pin Count | 2 |
| Maximum Reverse Leakage Current | 200nA |
| Length | 7.15mm |
| Width | 6.25mm |
| Dimensions | 7.15 x 2.25 x 6.25mm |
| Height | 2.25mm |
| Maximum Operating Temperature | +150 °C |
| Minimum Operating Temperature | -55 °C |
