Liên hệ để có giá tốt (Vietnam: 0898.332.898, E-mail: SKF@nguyenxuong.com)
| THÔNG SỐ KỸ THUẬT | |
|---|---|
| Nominal Zener Voltage | 7.5V |
| Diode Configuration | Single |
| Mounting Type | Through Hole |
| Number of Elements per Chip | 1 |
| Maximum Power Dissipation | 5 W |
| Package Type | CASE 017AA |
| Zener Type | Voltage Regulator |
| Zener Voltage Tolerance | ±5% |
| Pin Count | 2 |
| Maximum Zener Impedance | 1.5Ω |
| Maximum Reverse Leakage Current | 10µA |
| Dimensions | 3.68 Dia. x 8.89mm |
| Diameter | 3.68mm |
| Minimum Operating Temperature | -65 °C |
| Power Dissipation | 5W |
| Height | 8.89mm |
| Maximum Operating Temperature | +200 °C |
| Forward Voltage | 1.2V |
| Forward Current | 1A |
