| THÔNG SỐ KỸ THUẬT | |
|---|---|
| Nominal Zener Voltage | 4.7V |
| Diode Configuration | Single |
| Number of Elements per Chip | 1 |
| Mounting Type | Through Hole |
| Maximum Power Dissipation | 500 mW |
| Package Type | DO-35 |
| Zener Type | General Purpose |
| Zener Voltage Tolerance | 0.05 |
| Pin Count | 2 |
| Test Current | 20mA |
| Maximum Zener Impedance | 19 Ω @ 20 mA, 1900 Ω @ 0.25 mA |
| Maximum Reverse Leakage Current | 5µA |
| Dimensions | 1.91 Dia. x 4.56mm |
| Diameter | 1.91mm |
| Minimum Operating Temperature | -65 °C |
| Height | 4.56mm |
| Maximum Operating Temperature | +200 °C |
| Power Dissipation | 500mW |
| Forward Voltage | 1.2V |
| Forward Current | 200mA |
| Typical Voltage Temperature Coefficient | ±0.03%/°C |
