Wurth WE-LHMI Series Type 8040 Shielded Wire-wound SMD Inductor with a Iron Core, 680 nH Moulded 15A Idc [744373580068]; 163-7869
0₫
Mã kho: 1637869
Liên hệ để có giá tốt (Vietnam: 0898.332.898, E-mail: SKF@nguyenxuong.com)
| THÔNG SỐ KỸ THUẬT | |
|---|---|
| Inductance | 680 nH |
| Maximum DC Current | 15A |
| Package/Case | 8040 |
| Length | 9.7mm |
| Depth | 8.5mm |
| Height | 4mm |
| Dimensions | 9.7 x 8.5 x 4mm |
| Shielded | Yes |
| Maximum DC Resistance | 3.22mΩ |
| Series | WE-LHMI |
| Core Material | Iron |
| Maximum Self Resonant Frequency | 45MHz |
| Maximum Operating Temperature | +125°C |
| Moulded | Yes |
| Minimum Operating Temperature | -40°C |
| Inductor Construction | Moulded |
