Murata 6000B Series Wire-wound SMD Inductor 680 μH ±15% Wire-Wound 3A Idc [60B684C]; 106-8553
0₫
Mã kho: 1068553
Liên hệ để có giá tốt (Vietnam: 0898.332.898, E-mail: SKF@nguyenxuong.com)
| THÔNG SỐ KỸ THUẬT | |
|---|---|
| Inductance | 680 μH |
| Maximum DC Current | 3A |
| Length | 27mm |
| Depth | 19.5mm |
| Height | 20mm |
| Dimensions | 27 x 19.5 x 20mm |
| Tolerance | ±15% |
| Maximum DC Resistance | 135mΩ |
| Series | 6000B |
| Maximum Self Resonant Frequency | 1.59MHz |
| Maximum Operating Temperature | +85°C |
| Minimum Operating Temperature | -40°C |
| Inductor Construction | Wire-Wound |
