Murata 6000B Series Wire-wound SMD Inductor 68 μH ±15% Wire-Wound 9A Idc [60B683C]; 749-6405
0₫
Mã kho: 7496405
Liên hệ để có giá tốt (Vietnam: 0898.332.898, E-mail: SKF@nguyenxuong.com)
| THÔNG SỐ KỸ THUẬT | |
|---|---|
| Inductance | 68 μH |
| Maximum DC Current | 9A |
| Length | 27mm |
| Depth | 19.5mm |
| Height | 20mm |
| Dimensions | 27 x 19.5 x 20mm |
| Tolerance | ±15% |
| Maximum DC Resistance | 17mΩ |
| Series | 6000B |
| Maximum Self Resonant Frequency | 6.07MHz |
| Inductor Construction | Wire-Wound |
| Maximum Operating Temperature | +85°C |
| Minimum Operating Temperature | -40°C |
