Cooper Bussmann DR73/74/125/127 Series Type 0127 Shielded Wire-wound SMD Inductor with a Ferrite Core, 3.3 μH ±20% [DR127-3R3-R]; 770-1038
0₫
Mã kho: 7701038
Liên hệ để có giá tốt (Vietnam: 0898.332.898, E-mail: SKF@nguyenxuong.com)
| THÔNG SỐ KỸ THUẬT | |
|---|---|
| Inductance | 3.3 μH |
| Maximum DC Current | 21.5A |
| Package/Case | 127 |
| Length | 12.5mm |
| Depth | 12.5mm |
| Height | 8mm |
| Dimensions | 12.5 x 12.5 x 8mm |
| Shielded | Yes |
| Tolerance | ±20% |
| Maximum DC Resistance | 5.67mΩ |
| Series | DR73/74/125/127 |
| Core Material | Ferrite |
| Maximum Self Resonant Frequency | 100kHz |
| Maximum Operating Temperature | +125°C |
| Minimum Operating Temperature | -40°C |
| Inductor Construction | Wire-Wound |
