Bourns SRU6025 Series Shielded Wire-wound SMD Inductor with a Ferrite Core, 33 μH ±30% Wire-Wound Q:12 [SRU6025-330Y]; 172-9720
by Bourns
0₫
Mã kho: 1729720
Liên hệ để có giá tốt (Vietnam: 0898.332.898, E-mail: SKF@nguyenxuong.com)
| THÔNG SỐ KỸ THUẬT | |
|---|---|
| Inductance | 33 μH |
| Length | 6.5mm |
| Depth | 6.2mm |
| Height | 2.5mm |
| Dimensions | 6.5 x 6.2 x 2.5mm |
| Shielded | Yes |
| Tolerance | ±30% |
| Maximum DC Resistance | 180mΩ |
| Series | SRU6025 |
| Core Material | Ferrite |
| Maximum Self Resonant Frequency | 12MHz |
| Minimum Quality Factor | 12 |
| Minimum Operating Temperature | -40°C |
| Maximum Operating Temperature | +125°C |
| Inductor Construction | Wire-Wound |
