Bourns CM45 Series Type 1812 Wire-wound SMD Inductor with a Ferrite Core, 330 nH ±20% Wire-Wound 605mA Idc Q:40 [CM453232-R33ML]; 693-4375
by Bourns
0₫
Mã kho: 6934375
Liên hệ để có giá tốt (Vietnam: 0898.332.898, E-mail: SKF@nguyenxuong.com)
| THÔNG SỐ KỸ THUẬT | |
|---|---|
| Inductance | 330 nH |
| Maximum DC Current | 605mA |
| Package/Case | 1812 (4532M) |
| Length | 4.5mm |
| Depth | 3.2mm |
| Height | 3.2mm |
| Dimensions | 4.5 x 3.2 x 3.2mm |
| Tolerance | ±20% |
| Maximum DC Resistance | 280mΩ |
| Series | CM45 |
| Core Material | Ferrite |
| Maximum Self Resonant Frequency | 165MHz |
| Minimum Quality Factor | 40 |
| Inductor Construction | Wire-Wound |
| Minimum Operating Temperature | -40°C |
| Maximum Operating Temperature | +100°C |
