Bourns CM45 Series Type 1812 Wire-wound SMD Inductor with a Ferrite Core, 47 μH ±10% Wire-Wound 140mA Idc Q:50 [CM453232-470KL]; 172-9537
by Bourns
0₫
Mã kho: 1729537
Liên hệ để có giá tốt (Vietnam: 0898.332.898, E-mail: SKF@nguyenxuong.com)
THÔNG SỐ KỸ THUẬT | |
---|---|
Inductance | 47 μH |
Maximum DC Current | 140mA |
Package/Case | 1812 (4532M) |
Length | 4.5mm |
Depth | 3.2mm |
Height | 3.2mm |
Dimensions | 4.5 x 3.2 x 3.2mm |
Tolerance | ±10% |
Maximum DC Resistance | 5Ω |
Series | CM45 |
Core Material | Ferrite |
Maximum Self Resonant Frequency | 10MHz |
Minimum Operating Temperature | -40°C |
Maximum Operating Temperature | +100°C |
Inductor Construction | Wire-Wound |
Minimum Quality Factor | 50 |
