Bourns CM45 Series Type 1812 Wire-wound SMD Inductor with a Ferrite Core, 1 mH ±10% Wire-Wound 30mA Idc [CM453232-102KL]; 172-9531
by Bourns
0₫
Mã kho: 1729531
Liên hệ để có giá tốt (Vietnam: 0898.332.898, E-mail: SKF@nguyenxuong.com)
| THÔNG SỐ KỸ THUẬT | |
|---|---|
| Inductance | 1 mH |
| Maximum DC Current | 30mA |
| Package/Case | 1812 (4532M) |
| Length | 4.5mm |
| Depth | 3.2mm |
| Height | 3.2mm |
| Dimensions | 4.5 x 3.2 x 3.2mm |
| Tolerance | ±10% |
| Maximum DC Resistance | 40Ω |
| Series | CM45 |
| Core Material | Ferrite |
| Maximum Self Resonant Frequency | 2.5MHz |
| Moulded | Yes |
| Maximum Operating Temperature | +125°C |
| Inductor Construction | Wire-Wound |
| Minimum Operating Temperature | -40°C |
