Bourns CM32 Series Type 1210 Wire-wound SMD Inductor with a Ferrite Core, 330 nH ±20% Wire-Wound 330mA Idc Q:25 [CM322522-R33ML]; 172-9519
by Bourns
0₫
Mã kho: 1729519
Liên hệ để có giá tốt (Vietnam: 0898.332.898, E-mail: SKF@nguyenxuong.com)
| THÔNG SỐ KỸ THUẬT | |
|---|---|
| Inductance | 330 nH |
| Maximum DC Current | 330mA |
| Package/Case | 1210 (3225M) |
| Length | 3.2mm |
| Depth | 2.5mm |
| Height | 2.2mm |
| Dimensions | 3.2 x 2.5 x 2.2mm |
| Tolerance | ±20% |
| Maximum DC Resistance | 350mΩ |
| Series | CM32 |
| Core Material | Ferrite |
| Maximum Self Resonant Frequency | 190MHz |
| Maximum Operating Temperature | +100°C |
| Minimum Operating Temperature | -40°C |
| Minimum Quality Factor | 25 |
| Inductor Construction | Wire-Wound |
