Yageo TC164 Series 10kΩ ±5% Isolated SMT Resistor Array, 4 Resistors, 1/16W total 1206 (3216M) package Concave [TC164-JR-0710KL]; 618-6807
by Yageo
0₫
Mã kho: 6186807
Liên hệ để có giá tốt (Vietnam: 0898.332.898, E-mail: SKF@nguyenxuong.com)
| THÔNG SỐ KỸ THUẬT | |
|---|---|
| Resistance | 10 kΩ |
| Number of Resistors | 4 |
| Package/Case | 1206 (3216M) |
| Power Rating | 1/16W |
| Termination Style | Concave |
| Tolerance | ±5% |
| Case Style | Moulded |
| Power Rating per Resistor | 1/16W |
| Circuit Designator | ISOL |
| Length | 3.2mm |
| Depth | 1.6mm |
| Height | 0.6mm |
| Dimensions | 3.2 x 1.6 x 0.6mm |
| Series | TC164 |
| Number of Terminals | 8 |
| Minimum Operating Temperature | -55°C |
| Temperature Coefficient | ±200ppm/°C |
| Maximum Operating Temperature | +155°C |
