Wachendorff Incremental Encoder 5000 ppr 8000rpm 4.75 → 5.5 V dc [WDG58B-5000-ABN-I05-K3]; 388-5624
by Wachendorff
0₫
Mã kho: 3885624
Liên hệ để có giá tốt (Vietnam: 0898.332.898, E-mail: SKF@nguyenxuong.com)
THÔNG SỐ KỸ THUẬT | |
---|---|
Pulses Per Revolution | 5000 |
Encoder Technology | Incremental |
Maximum Revolutions | 8000rpm |
Output Signal Type | TTL Inverted |
Shaft Type | Solid |
Supply Voltage | 4.75 → 5.5 V dc |
IP Rating | IP65, IP67 |
Overall Height | 83mm |
Minimum Operating Temperature | -20°C |
Maximum Operating Temperature | +80°C |
Mounting Type | Clamping Flange |
Switching Frequency | 200 kHz |
