TRACOPOWER TVN 5WI 5W Isolated DC-DC Converter Through Hole, Voltage in 9 → 36 V dc, Voltage out 24V dc [TVN 5-2415WI]; 166-6327
by TRACOPOWER
0₫
Mã kho: 1666327
Liên hệ để có giá tốt (Vietnam: 0898.332.898, E-mail: SKF@nguyenxuong.com)
| THÔNG SỐ KỸ THUẬT | |
|---|---|
| Output Voltage | 24V dc |
| Input Voltage Range | 9 → 36 V dc |
| Input Voltage Nominal | 24 V dc |
| Isolation Voltage | 1.5kV dc |
| Power Rating | 5W |
| Output Current | 208mA |
| Mounting Type | Through Hole |
| Number of Outputs | 1 |
| Efficiency | 0.91 |
| Minimum Temperature | -40°C |
| Load Regulation | 0.005 |
| Maximum Temperature | +46°C |
| Depth | 0.43mm |
| Series | TVN 5WI |
| Length | 50.8mm |
