DC/DC Converter Isolated +/-24V 40W [TEN 40-2425WIE]; 194-4666
by TRACOPOWER
0₫
Mã kho: 1944666
Liên hệ để có giá tốt (Vietnam: 0898.332.898, E-mail: SKF@nguyenxuong.com)
| THÔNG SỐ KỸ THUẬT | |
|---|---|
| Output Voltage | ±24V dc |
| Output Voltage Adjustment Range | -10 → 20% |
| Input Voltage Range | 9 → 36 V dc |
| Power Rating | 40W |
| Output Current | 833mA |
| Isolation Voltage | 1.131 kV dc, 1.6 kV dc |
| Input Voltage Nominal | 24 V dc |
| Mounting Type | Through Hole |
| Number of Outputs | 2 |
| Efficiency | 91 (Typ.)% |
| Package | 2 in x 1 in Case |
| Minimum Temperature | -40°C |
| Load Regulation | 0.005 |
| Maximum Temperature | +85°C |
| Width | 25.4mm |
| Depth | 10.2mm |
| Series | TEN 40WIE |
| Length | 50.8mm |
