DC/DC Converter Isolated +/-15V 40W [TEN 40-1223E]; 194-4612
by TRACOPOWER
0₫
Mã kho: 1944612
Liên hệ để có giá tốt (Vietnam: 0898.332.898, E-mail: SKF@nguyenxuong.com)
THÔNG SỐ KỸ THUẬT | |
---|---|
Output Voltage | ±15V dc |
Output Voltage Adjustment Range | -10 → 20% |
Power Rating | 40W |
Input Voltage Range | 9 → 18 V dc |
Output Current | 1.33A |
Isolation Voltage | 1.131 kV dc, 1.6 kV dc |
Input Voltage Nominal | 12 V dc |
Mounting Type | Through Hole |
Number of Outputs | 2 |
Efficiency | 90 (Typ.)% |
Package | 2 in x 1 in Case |
Minimum Temperature | -40°C |
Load Regulation | 0.005 |
Maximum Temperature | +85°C |
Length | 50.8mm |
Series | TEN 40E |
Depth | 10.2mm |
Width | 25.4mm |
