TDK-Lambda RFE-2500-48 Rack Mount Power Supply 85 → 265V ac 48V dc 52A 1 Outputs 2496W 93% 240mV 120mV [RFE-2500-48]; 124-2217
by TDK-Lambda
0₫
Mã kho: 1242217
Liên hệ để có giá tốt (Vietnam: 0898.332.898, E-mail: SKF@nguyenxuong.com)
| THÔNG SỐ KỸ THUẬT | |
|---|---|
| Load Regulation | 240mV |
| Input Voltage | 85 → 265V ac |
| Output Voltage | 48 V dc |
| Output Current | 52A |
| Power Rating | 2496W |
| Number of Outputs | 1 |
| Mounting Type | Rack Mount |
| Type | Switch Mode |
| Line Regulation | 120mV |
| Ripple And Noise | 480mV Pk-Pk |
| Weight | 2.5kg |
| Output Voltage Adjustment Range | 38.4 → 58V |
| Maximum Input Current | 15A |
| Minimum Temperature | -10°C |
| Application | Communication, Industrial, Test |
| Protection Features | Over Current Protection, Over Temperature Protection, Over Voltage Protection |
| Power Signal Conversion Type | AC-DC |
| Maximum Temperature | +70°C |
| Standards Met | CE, COTS, EN 55022, EN 60950-1, EN 61000-3-2, FCC, IEC 61000-4-11, IEC 61000-4-2, IEC 61000-4-3, IEC 61000-4-4, IEC 61000-4-5, IEC 61000-4-6, IEC 61000-4-8, IEC 61068-2-27, IEC 61068-2-64, UL 60950-1 |
| Input Frequency Range | 47 → 63Hz |
| Holdup Time | >10ms |
| Series | RFE2500 |
| Allowed Circuit Configurations | Parallel |
| Special Features | High Efficiency, Internal ORing FETs & Current Share, 1U High |
