TSV914IDT STMicroelectronics, High Speed, Op Amp, RRIO, 8MHz, 3 V, 5 V, 14-Pin SOIC [TSV914IDT]; 168-6426
0₫
Mã kho: 1686426
Liên hệ để có giá tốt (Vietnam: 0898.332.898, E-mail: SKF@nguyenxuong.com)
| THÔNG SỐ KỸ THUẬT | |
|---|---|
| Amplifier Type | High Speed |
| Mounting Type | Surface Mount |
| Package Type | SOIC |
| Power Supply Type | Single |
| Number of Channels per Chip | 4 |
| Pin Count | 14 |
| Typical Single Supply Voltage | 3 V, 5 V |
| Typical Gain Bandwidth Product | 8MHz |
| Typical Slew Rate | 4.5V/µs |
| Minimum Operating Temperature | -40 °C |
| Maximum Operating Temperature | +125 °C |
| Dimensions | 8.75 x 4 x 1.65mm |
| Typical Voltage Gain | 91 dB |
| Width | 4mm |
| Height | 1.65mm |
| Rail to Rail | Rail to Rail Input/Output |
| Typical Input Voltage Noise Density | 27nV/√Hz |
| Length | 8.75mm |
