| THÔNG SỐ KỸ THUẬT | |
|---|---|
| Mounting Type | Surface Mount |
| Package Type | SO |
| Power Supply Type | Dual, Single |
| Number of Channels per Chip | 2 |
| Pin Count | 8 |
| Typical Single Supply Voltage | 3 → 30 V |
| Typical Gain Bandwidth Product | 25MHz |
| Typical Dual Supply Voltage | ±1.5 to ±15V |
| Typical Slew Rate | 15V/µs |
| Maximum Operating Temperature | +125 °C |
| Minimum Operating Temperature | -40 °C |
| Height | 1.65mm |
| Typical Voltage Gain | 100 V/mV |
| Input Offset Current | 65nA |
| Input Voltage Range | 3 → 30 V |
| Width | 6.2mm |
| Maximum Input Voltage | 30 V |
| Output Current | 37 mA |
| Dimensions | 5 x 6.2 x 1.65mm |
| Length | 5mm |
| Minimum Input Voltage | 3 V |
| Offset Voltage | 2.5mV |
