STMicroelectronics 200V 120A, Dual Diode, 4-Pin ISOTOP STTH20002TV1 [STTH20002TV1]; 168-6630
0₫
Mã kho: 1686630
Liên hệ để có giá tốt (Vietnam: 0898.332.898, E-mail: SKF@nguyenxuong.com)
| THÔNG SỐ KỸ THUẬT | |
|---|---|
| Mounting Type | Panel Mount |
| Package Type | ISOTOP |
| Maximum Continuous Forward Current | 120A |
| Peak Reverse Repetitive Voltage | 200V |
| Diode Configuration | Isolated |
| Rectifier Type | Switching |
| Diode Type | Silicon Junction |
| Pin Count | 4 |
| Maximum Forward Voltage Drop | 1.2V |
| Number of Elements per Chip | 2 |
| Diode Technology | Silicon Junction |
| Peak Reverse Recovery Time | 50ns |
| Peak Non-Repetitive Forward Surge Current | 1kA |
