STMicroelectronics STM32L051C8T6, 32bit ARM Cortex M0+ Microcontroller, 32MHz, 64 kB Flash, 48-Pin LQFP [STM32L051C8T6]; 166-1142
0₫
Mã kho: 1661142
Liên hệ để có giá tốt (Vietnam: 0898.332.898, E-mail: SKF@nguyenxuong.com)
| THÔNG SỐ KỸ THUẬT | |
|---|---|
| Family Name | STM32 |
| Package Type | LQFP |
| Mounting Type | Surface Mount |
| Pin Count | 48 |
| Device Core | ARM Cortex M0+ |
| Data Bus Width | 32bit |
| Program Memory Size | 64 kB |
| Maximum Frequency | 32MHz |
| RAM Size | 8 kB |
| ADC Channels | 10 |
| Typical Operating Supply Voltage | 1.65 → 3.6 V |
| Timers | 4 x 16 bit |
| Minimum Operating Temperature | -40 °C |
| Dimensions | 7.2 x 7.2 x 1.45mm |
| Instruction Set Architecture | RISC |
| Height | 1.45mm |
| Number of ADC Units | 1 |
| Program Memory Type | Flash |
| Maximum Operating Temperature | +85 °C |
| Number of Timers | 4 |
| ADCs | 1 (10 x 12 bit) |
| Length | 7.2mm |
| Timer Resolution | 16bit |
| ADC Resolution | 12bit |
| Data Rate | 4Mbps |
| Width | 7.2mm |
