STMicroelectronics STM32L051C8T6, 32bit ARM Cortex M0+ Microcontroller, 32MHz, 64 kB Flash, 48-Pin LQFP [STM32L051C8T6]; 110-6622
0₫
Mã kho: 1106622
Liên hệ để có giá tốt (Vietnam: 0898.332.898, E-mail: SKF@nguyenxuong.com)
THÔNG SỐ KỸ THUẬT | |
---|---|
Family Name | STM32 |
Package Type | LQFP |
Mounting Type | Surface Mount |
Pin Count | 48 |
Device Core | ARM Cortex M0+ |
Data Bus Width | 32bit |
Program Memory Size | 64 kB |
Maximum Frequency | 32MHz |
RAM Size | 8 kB |
ADC Channels | 10 |
Typical Operating Supply Voltage | 1.65 → 3.6 V |
Number of Timers | 4 |
Dimensions | 7.2 x 7.2 x 1.45mm |
Instruction Set Architecture | RISC |
Minimum Operating Temperature | -40 °C |
ADC Resolution | 12bit |
Number of ADC Units | 1 |
Program Memory Type | Flash |
Timers | 4 x 16 bit |
Height | 1.45mm |
Width | 7.2mm |
Data Rate | 4Mbps |
ADCs | 1 (10 x 12 bit) |
Length | 7.2mm |
Maximum Operating Temperature | +85 °C |
Timer Resolution | 16bit |
