![STMicroelectronics STM32F446RET6 1106621](http://nguyenxuong.com/cdn/shop/products/R1106621-01_82a64a5f-7c28-4dcb-8894-1cf3df36d5ca_444x389.jpg?v=1594317319)
STMicroelectronics STM32F446RET6, 32bit ARM Cortex M4 MCU, 180MHz, 512 kB Flash, 64-Pin LQFP [STM32F446RET6]; 110-6621
0₫
Mã kho: 1106621
Liên hệ để có giá tốt (Vietnam: 0898.332.898, E-mail: SKF@nguyenxuong.com)
THÔNG SỐ KỸ THUẬT | |
---|---|
Family Name | STM32 |
Package Type | LQFP |
Mounting Type | Surface Mount |
Pin Count | 64 |
Device Core | ARM Cortex M4 |
Data Bus Width | 32bit |
Program Memory Size | 512 kB |
Maximum Frequency | 180MHz |
RAM Size | 128 kB |
USB Channels | 2 |
ADC Channels | 16 |
Typical Operating Supply Voltage | 1.8 → 3.6 V |
Program Memory Type | Flash |
Number of Timers | 12 |
Data Rate | 45Mbps |
Dimensions | 10 x 10 x 1.45mm |
Timers | 2 x 32 bit, 12 x 16 bit |
Number of ADC Units | 3 |
Width | 10mm |
Maximum Operating Temperature | +85 °C |
Instruction Set Architecture | RISC |
ADCs | 3 (16 x 12 bit) |
ADC Resolution | 12bit |
Timer Resolution | 16 bit, 32 bit |
Height | 1.45mm |
Minimum Operating Temperature | -40 °C |
Length | 10mm |
