STMicroelectronics STM32F407ZGT7, 32bit ARM Cortex M4 MCU, 168MHz, 1.024 MB Flash, 144-Pin LQFP [STM32F407ZGT7]; 166-0841
0₫
Mã kho: 1660841
Liên hệ để có giá tốt (Vietnam: 0898.332.898, E-mail: SKF@nguyenxuong.com)
| THÔNG SỐ KỸ THUẬT | |
|---|---|
| Family Name | STM32 |
| Package Type | LQFP |
| Mounting Type | Surface Mount |
| Pin Count | 144 |
| Device Core | ARM Cortex M4 |
| Data Bus Width | 32bit |
| Program Memory Size | 1.024 MB |
| Maximum Frequency | 168MHz |
| RAM Size | 192 kB |
| USB Channels | 2 |
| ADC Channels | 24 |
| Typical Operating Supply Voltage | 1.8 → 3.6 V |
| ADCs | 3 (24 x 12 bit) |
| Program Memory Type | Flash |
| Length | 20.2mm |
| Number of Timers | 12 |
| Number of ADC Units | 3 |
| Instruction Set Architecture | RISC |
| Maximum Operating Temperature | +105 °C |
| Dimensions | 20.2 x 20.2 x 1.45mm |
| Minimum Operating Temperature | -40 °C |
| Timers | 2 x 32 bit, 12 x 16 bit |
| ADC Resolution | 12bit |
| Maximum Number of Ethernet Channels | 1 |
| Data Rate | 100Mbps |
| Width | 20.2mm |
| Height | 1.45mm |
| Timer Resolution | 16 bit, 32 bit |
