STMicroelectronics KF33BD-TR, LDO Regulator, 500mA, 3.3 V, ±2% 8-Pin, SOIC [KF33BD-TR]; 168-6537
0₫
Mã kho: 1686537
Liên hệ để có giá tốt (Vietnam: 0898.332.898, E-mail: SKF@nguyenxuong.com)
| THÔNG SỐ KỸ THUẬT | |
|---|---|
| Output Voltage | 3.3 V |
| Output Type | Fixed |
| Package Type | SOIC |
| Maximum Output Current | 500mA |
| Mounting Type | Surface Mount |
| Minimum Input Voltage | -0.5 V |
| Maximum Input Voltage | 20 V |
| Pin Count | 8 |
| Number of Outputs | 1 |
| Polarity | Positive |
| Quiescent Current | 0.5mA |
| Accuracy | ±2% |
| Minimum Operating Temperature | -40 °C |
| Maximum Operating Temperature | +125 °C |
| Length | 5mm |
| Line Regulation | 12 mV |
| Load Regulation | 50 mV |
| Height | 1.65mm |
| Width | 4mm |
| Dimensions | 5 x 4 x 1.65mm |
| Enable | Yes |
