Souriau Series III Series, 13 Way Cable Mount MIL Spec Circular Connector Plug, Pin Contacts,Shell Size 11 [8D 5 11 W 35 PN]; 687-6777
by Souriau
0₫
Mã kho: 6876777
Liên hệ để có giá tốt (Vietnam: 0898.332.898, E-mail: SKF@nguyenxuong.com)
THÔNG SỐ KỸ THUẬT | |
---|---|
Number of Contacts | 13 |
Gender | Male |
Contact Gender | Male |
Current Rating | 5A |
Shell Size | 11 |
Mounting Type | Cable Mount |
Military Standard | MIL-DTL-38999 |
Termination Method | Crimp |
Mating Type | Screw Coupling |
Body Orientation | Straight |
Series | Series III |
Maximum Operating Temperature | +175°C |
Contact Plating | Gold over Nickel |
Shell Plating | Olive Drab Cadmium |
Minimum Operating Temperature | -65°C |
Contact Material | Copper Alloy |
