Semikron, SK 100 KQ 16, Dual Thyristor Module, SCR, 18A 1600V, 3-Pin B 2 [SK 100 KQ 16]; 905-6043
by Semikron
0₫
Mã kho: 9056043
Liên hệ để có giá tốt (Vietnam: 0898.332.898, E-mail: SKF@nguyenxuong.com)
| THÔNG SỐ KỸ THUẬT | |
|---|---|
| Thyristor Type | SCR |
| Maximum Gate Trigger Voltage | 3 (Min)V |
| Maximum Gate Trigger Current | 100 (Min)mA |
| Maximum Holding Current | 150mA |
| Rated Average On-State Current | 18A |
| Repetitive Peak Reverse Voltage | 1600V |
| Surge Current Rating | 370A |
| Mounting Type | Thread Mount |
| Package Type | B 2 |
| Pin Count | 3 |
| Peak On-State Voltage | 2.4V |
| Repetitive Peak Forward Blocking Voltage | 1600V |
| Repetitive Peak Off-State Current | 8mA |
| Dimensions | 14 (Dia.) x 41mm |
| Height | 41mm |
| Maximum Operating Temperature | +130 °C |
| Minimum Operating Temperature | -40 °C |
| Width | 14mm |
