Samtec, IsoRate IP5, 2 Way, 1 Row, Straight PCB Header [IP5-02-05.0-L-S-1-TR]; 123-6928
by Samtec
0₫
Mã kho: 1236928
Liên hệ để có giá tốt (Vietnam: 0898.332.898, E-mail: SKF@nguyenxuong.com)
THÔNG SỐ KỸ THUẬT | |
---|---|
Series | IsoRate IP5 |
Pitch | 4mm |
Number of Contacts | 2 |
Number of Rows | 1 |
Body Orientation | Straight |
Shrouded/Unshrouded | Shrouded |
Mounting Type | Through Hole |
Connector System | Board to Board |
Termination Method | Solder |
Contact Material | Copper Alloy |
Contact Plating | Gold |
Current Rating | 2.3A |
