Rubycon 1000μF 80V dc Aluminium Electrolytic Capacitor, Through Hole 16 (Dia.) x 40mm +105°C 16mm 7.5mm [80ZLH1000MEFCCE16X40]; 172-8125
by Rubycon
0₫
Mã kho: 1728125
Liên hệ để có giá tốt (Vietnam: 0898.332.898, E-mail: SKF@nguyenxuong.com)
| THÔNG SỐ KỸ THUẬT | |
|---|---|
| Capacitance | 1000 µF |
| Voltage | 80 V dc |
| Mounting Type | Through Hole |
| Technology | Electrolytic |
| Dimensions | 16 (Dia.) x 40mm |
| Height | 40mm |
| Minimum Operating Temperature | -40°C |
| Diameter | 16mm |
| Maximum Operating Temperature | +105°C |
| Lifetime | 10000h |
| Lead Pitch | 7.5mm |
| Series | ZLH |
| Ripple Current | 2.86A |
| Leakage Current | 0.01 CV or 3 μA |
| Tolerance | ±20% |
