![Rubycon 63YXF100MEFCT810X12.5 1726215](http://nguyenxuong.com/cdn/shop/products/R191812-01_2824160d-63f7-4f16-a0a0-bf8caf9f5be8_444x151.jpg?v=1594413770)
Rubycon 100μF 63V dc Aluminium Electrolytic Capacitor, Through Hole 10 (Dia.) x 12.5mm +105°C 10mm 5mm [63YXF100MEFCT810X12.5]; 172-6215
by Rubycon
0₫
Mã kho: 1726215
Liên hệ để có giá tốt (Vietnam: 0898.332.898, E-mail: SKF@nguyenxuong.com)
THÔNG SỐ KỸ THUẬT | |
---|---|
Capacitance | 100 µF |
Voltage | 63 V dc |
Mounting Type | Through Hole |
Technology | Electrolytic |
Dimensions | 10 (Dia.) x 12.5mm |
Height | 12.5mm |
Minimum Operating Temperature | -40°C |
Diameter | 10mm |
Maximum Operating Temperature | +105°C |
Lead Pitch | 5mm |
Lifetime | 7000h |
Series | YXF |
Ripple Current | 300mA |
Leakage Current | 0.01 CV or 3 μA |
Tolerance | ±20% |
