Rubycon 1200μF 6.3V dc Aluminium Electrolytic Capacitor, Through Hole 10 (Dia.) x 16mm +105°C 10mm 5mm [6.3YXG1200MEFC10X16]; 704-7974
by Rubycon
0₫
Mã kho: 7047974
Liên hệ để có giá tốt (Vietnam: 0898.332.898, E-mail: SKF@nguyenxuong.com)
| THÔNG SỐ KỸ THUẬT | |
|---|---|
| Capacitance | 1200 µF |
| Voltage | 6.3 V dc |
| Mounting Type | Through Hole |
| Technology | Electrolytic |
| Dimensions | 10 (Dia.) x 16mm |
| Height | 16mm |
| Minimum Operating Temperature | -40°C |
| Diameter | 10mm |
| Maximum Operating Temperature | +105°C |
| Lifetime | 5000h |
| Lead Pitch | 5mm |
| Series | YXG |
| Ripple Current | 1.21A |
| Tolerance | ±20% |
| Leakage Current | 0.01 CV or 3 μA |
