![Rubycon 50SGV100M8X10.5 1726197](http://nguyenxuong.com/cdn/shop/products/R0568509-01_9bb15fba-ef64-4c5b-a440-ae74913b02a5_354x356.jpg?v=1594313012)
Rubycon 100μF 50V dc Aluminium Electrolytic Capacitor, Surface Mount 8 (Dia.) x 10.5mm +105°C 8mm 3.1mm [50SGV100M8X10.5]; 172-6197
by Rubycon
0₫
Mã kho: 1726197
Liên hệ để có giá tốt (Vietnam: 0898.332.898, E-mail: SKF@nguyenxuong.com)
THÔNG SỐ KỸ THUẬT | |
---|---|
Capacitance | 100 µF |
Voltage | 50 V dc |
Mounting Type | Surface Mount |
Technology | Electrolytic |
Dimensions | 8 (Dia.) x 10.5mm |
Height | 10.5mm |
Minimum Operating Temperature | -55°C |
Diameter | 8mm |
Maximum Operating Temperature | +105°C |
Lead Pitch | 3.1mm |
Lifetime | 2000h |
Series | SVG |
Ripple Current | 230mA |
Leakage Current | 0.01 CV or 3 μA |
Polarised | Polar |
Tolerance | ±20% |
