Rubycon 220μF 50V dc Aluminium Electrolytic Capacitor, Through Hole 10 (Dia.) x 20mm +130°C 10mm 5mm [50RX30220M10X20]; 172-8026
by Rubycon
0₫
Mã kho: 1728026
Liên hệ để có giá tốt (Vietnam: 0898.332.898, E-mail: SKF@nguyenxuong.com)
| THÔNG SỐ KỸ THUẬT | |
|---|---|
| Capacitance | 220 µF |
| Voltage | 50 V dc |
| Mounting Type | Through Hole |
| Technology | Electrolytic |
| Dimensions | 10 (Dia.) x 20mm |
| Height | 20mm |
| Minimum Operating Temperature | -40°C |
| Diameter | 10mm |
| Maximum Operating Temperature | +130°C |
| Lifetime | 2000h |
| Lead Pitch | 5mm |
| Series | RX30 |
| Leakage Current | 0.01 CV or 3 μA |
| Ripple Current | 890mA |
| Tolerance | ±20% |
