Rubycon 4.7μF 50V dc Aluminium Electrolytic Capacitor, Through Hole 5 (Dia.) x 5mm +85°C 5mm 2mm [50MS54R7MEFC5X5]; 172-7409
by Rubycon
0₫
Mã kho: 1727409
Liên hệ để có giá tốt (Vietnam: 0898.332.898, E-mail: SKF@nguyenxuong.com)
| THÔNG SỐ KỸ THUẬT | |
|---|---|
| Capacitance | 4.7 µF |
| Voltage | 50 V dc |
| Mounting Type | Through Hole |
| Technology | Electrolytic |
| Dimensions | 5 (Dia.) x 5mm |
| Height | 5mm |
| Minimum Operating Temperature | -40°C |
| Diameter | 5mm |
| Maximum Operating Temperature | +85°C |
| Lead Pitch | 2mm |
| Lifetime | 1000h |
| Series | MS5 |
| Ripple Current | 20mA |
| Leakage Current | 0.01 CV or 3 μA |
| Tolerance | ±20% |
