Rubycon 15μF 450V dc Aluminium Electrolytic Capacitor, Through Hole 12.5 (Dia.) x 25mm +105°C 12.5mm 5mm [450BXC15MEFC12.5X25]; 172-8057
by Rubycon
0₫
Mã kho: 1728057
Liên hệ để có giá tốt (Vietnam: 0898.332.898, E-mail: SKF@nguyenxuong.com)
| THÔNG SỐ KỸ THUẬT | |
|---|---|
| Capacitance | 15 µF |
| Voltage | 450 V dc |
| Mounting Type | Through Hole |
| Technology | Electrolytic |
| Dimensions | 12.5 (Dia.) x 25mm |
| Height | 25mm |
| Minimum Operating Temperature | -25°C |
| Diameter | 12.5mm |
| Maximum Operating Temperature | +105°C |
| Lead Pitch | 5mm |
| Lifetime | 12000h |
| Series | BXC |
| Leakage Current | 0.02 CV + 25 (CV 1000) μA, 0.03 CV + 15 (CV = 1000) μA, 0.04 CV + 100 (CV 1000) μA, 0.1 CV + 40 (CV = 1000) μA |
| Tolerance | ±20% |
| Ripple Current | 600mA |
