Rubycon 100μF 400V dc Aluminium Electrolytic Capacitor, Through Hole 16 (Dia.) x 31.5mm +105°C 16mm 7.5mm [400CXW100MEFC16X31.5]; 172-7684
by Rubycon
0₫
Mã kho: 1727684
Liên hệ để có giá tốt (Vietnam: 0898.332.898, E-mail: SKF@nguyenxuong.com)
THÔNG SỐ KỸ THUẬT | |
---|---|
Capacitance | 100 µF |
Voltage | 400 V dc |
Mounting Type | Through Hole |
Technology | Electrolytic |
Dimensions | 16 (Dia.) x 31.5mm |
Height | 31.5mm |
Minimum Operating Temperature | -25°C |
Diameter | 16mm |
Maximum Operating Temperature | +105°C |
Lifetime | 5000h |
Lead Pitch | 7.5mm |
Series | CXW |
Tolerance | ±20% |
Ripple Current | 710mA |
Leakage Current | 3√CV μA |
