Rubycon 4700μF 35V dc Aluminium Electrolytic Capacitor, Through Hole 16 (Dia.) x 35.5mm +85°C 16mm 7.5mm [35PK4700MEFC16X35.5]; 172-8111
by Rubycon
0₫
Mã kho: 1728111
Liên hệ để có giá tốt (Vietnam: 0898.332.898, E-mail: SKF@nguyenxuong.com)
| THÔNG SỐ KỸ THUẬT | |
|---|---|
| Capacitance | 4700 µF |
| Voltage | 35 V dc |
| Mounting Type | Through Hole |
| Technology | Electrolytic |
| Dimensions | 16 (Dia.) x 35.5mm |
| Height | 35.5mm |
| Minimum Operating Temperature | -40°C |
| Diameter | 16mm |
| Maximum Operating Temperature | +85°C |
| Lead Pitch | 7.5mm |
| Lifetime | 2000h |
| Series | PK |
| Tolerance | ±20% |
| Leakage Current | 0.01 CV or 3 μA (After 2 min) |
| Ripple Current | 2500mArms |
