Rubycon 22μF 250V dc Aluminium Electrolytic Capacitor, Through Hole 10 (Dia.) x 16mm +105°C 10mm 5mm [250BXC22MEFC10X16]; 172-6235
by Rubycon
0₫
Mã kho: 1726235
Liên hệ để có giá tốt (Vietnam: 0898.332.898, E-mail: SKF@nguyenxuong.com)
| THÔNG SỐ KỸ THUẬT | |
|---|---|
| Capacitance | 22 µF |
| Voltage | 250 V dc |
| Mounting Type | Through Hole |
| Technology | Electrolytic |
| Dimensions | 10 (Dia.) x 16mm |
| Height | 16mm |
| Minimum Operating Temperature | -25°C |
| Diameter | 10mm |
| Maximum Operating Temperature | +105°C |
| Lead Pitch | 5mm |
| Lifetime | 10000h |
| Series | BXC |
| Ripple Current | 470mA |
| Tolerance | ±20% |
| Leakage Current | 0.02 CV + 25 (CV 1000) μA, 0.03 CV + 15 (CV = 1000) μA, 0.04 CV + 100 (CV 1000) μA, 0.1 CV + 40 (CV = 1000) μA |
