Rubycon 4.7μF 200V dc Aluminium Electrolytic Capacitor, Through Hole 6.3 x 11mm +105°C 6.3mm 2.5mm [200LLE4,7MEFC6.3X11]; 172-6160
by Rubycon
0₫
Mã kho: 1726160
Liên hệ để có giá tốt (Vietnam: 0898.332.898, E-mail: SKF@nguyenxuong.com)
| THÔNG SỐ KỸ THUẬT | |
|---|---|
| Capacitance | 4.7 µF |
| Voltage | 200 V dc |
| Mounting Type | Through Hole |
| Technology | Electrolytic |
| Dimensions | 6.3 x 11mm |
| Height | 11mm |
| Minimum Operating Temperature | -40°C |
| Diameter | 6.3mm |
| Maximum Operating Temperature | +105°C |
| Lead Pitch | 2.5mm |
| Lifetime | 12000h |
| Series | LLE |
| Tolerance | ±20% |
| Leakage Current | 0.03 CV + 15 μA (After 5 min), 0.1 CV + 40 μA (After 1 min) |
| Ripple Current | 49mArms |
